9-Series

Flow Wrappers With Semiautomatic and Automatic Feed, and Multiple Formats

Let's Talk

Overview

High-Performance Flow Wrapping for Regular Products

The FW-90, FW-900, and FW-9000 Flow Wrappers (featuring top film reel holders) are high-performance, servo-driven machines designed for reliable, efficient wrapping of regular products in various production environments. The FW-900 supports semi- or fully automatic feeding and multiple format changes, while the FW-9000 is the premium solution for high-speed production runs.

Key Features

  • Ideal for wrapping products at varying speeds
  • FW-90: Accommodates manual, semi-automatic, or automatic feeding and allows for numerous format changes
  • FW-900: Flexible for semi- or fully-automatic feeding
  • FW-9000: Optimized for high-speed, fully automatic production
  • Servo-driven controls for precision and smooth operation
  • Modular, cantilever design for fast changeovers and easy maintenance
  • Supports a wide range of accessories and feeding systems
  • Built to meet the most demanding packaging environment

Specs PDFs

Specifications

Safety Compliance CE Directive 98/37/CE CE Directive 89/336 CEE - 93/68/CEE CE Directive 72/23 CEE - 93/68/CEE EN 415-3 / EN 60204-1 / EN ISO 12100-1 / EN ISO 12100-2 / EN 294 / EN 418
Power Supply 480V 3ph
Electrical Consumption 12 - 32 amps
Air Consumption 2 cfm @ 90 psi
Noise Level Less than 80 db
Weight Between 2,200 - 3,300 lbs
Specs PDF See Bag Styles Let's Talk

Features

  • Pusher conveyor
  • Top reel holder
  • Universal forming box
  • Fixed forming box
  • Longitudinal sealing unit
  • Fin longitudinal sealing unit
  • Longitudinal welding module
  • End cutting and welding unit
  • Outfeed conveyor
  • Transmission cabinet
  • Intuitive touch screen human interface (HMI)
  • Automatic feed
  • Easy changeover
  • Modular construction
  • Minimal maintenance requirements
  • Poly configuration for polyethylene films
  • Thermo configuration for heat sealable films
  • Cold configuration for cold sealing films
  • Box Motion configuration for hermetic sealing
  • Rotary sealing and cutting unit for ultra high speeds
  • Robust stainless steel build
  • Robotic handling configuration for right hand execution
  • Integration with feeders
  • Integration with ancillary equipment
  • Allen Bradley controls
  • Automatic film splice

Compatible Applications

Bakery icon Bakery
Candy icon Candy
Cannabis+Food+Beverage icon Cannabis
Food & Beverage
Cannabis+Health+Medical icon Cannabis
Health & Medical
Cereal, Nuts & Snacks icon Cereal, Nuts & Snacks
Cheese icon Cheese
Fresh Fruit & Vegetables icon Fresh Fruit & Vegetables
Individual Quick Frozen (IQF) icon Individual Quick Frozen (IQF)
Meat, Poultry & Fish icon Meat, Poultry & Fish
Medical Devices & Supplies icon Medical Devices & Supplies
Medical Testing Kits icon Medical Testing Kits
Pasta, Beans & Rice icon Pasta, Beans & Rice
Pet Food & Treats icon Pet Food & Treats
Pills & Capsules icon Pills & Capsules
9-Series (FW-90, FW-900, FW-9000)

Options

  • Poly configuration for polyethylene films
  • Cold configuration for cold sealing films
  • Box Motion configuration for hermetic sealing
  • Robotic handling for right hand execution
  • Integration with feeders
  • ntegration with ancillary equipment
