8SU-180

Customize a Premade Pouch Machine to Suit Your Industry and Application

Let's Talk

Overview

A Powerful Pouch Filler & Sealer for Powders, Liquids, and Food Products

The Viking 8SU-180 is a versatile two-lane automatic premade pouch machine designed to fill and seal powders, liquids, and food products in pouches up to 180 mm wide. With speeds up to 80 bags per minute, it boosts throughput, seal quality, and overall efficiency. Add in its compatibility with Standcap Pouch pouches, and the Viking 8SU-180 is a smart solution for a wide range of industries and applications.

Key Features

  • Two-lane duplex operation for high-speed output
  • Supports powders, liquids, and solid food products
  • Compatible with Standcap Pouch pouch formats
  • Customizable for industry-specific needs and integration

Specifications

Number of Stations 8
Number of Lanes 2
Maximum Speed Per Minute (dry cycle) 80
Bag Gripping Range (mm) 100-180mm
Maximum Bag Length (mm) 350mm
Electrical Requirements 3-Phase, 480V, Approx. 4.5 Kw, 60Hz
Compressed Air Approx. 700 NL/min, 5~6 kgf/cm2
Specs PDF See Bag Styles Let's Talk

Features

  • 8 stations, dual bags
  • Dual bag grippers (no center gripper)
  • PLC control with touch screen operation
  • Servo-driven Allen Bradley control platform
  • Highly durable welded steel frame
  • Production parameter memory including gripper size, machine speed, sealing temperature, and filling volume
  • Pouch presence detection – no filling, no sealing
  • Bag deflation with wire guide or push bars
  • Automatic deoxidizer feeding station
  • Two step sealing process guarantees clean sealing
  • Cooling station for liquid products
  • Intuitive touch screen human interface (HMI)

Max Speed

80 bpm

Bag Size

Min 100 mm W x 120 mm L

Max180 mm W x 350 mm L

Compatible Applications

Candy icon Candy
Cannabis+Food+Beverage icon Cannabis
Food & Beverage
Cannabis+Health+Medical icon Cannabis
Health & Medical
Cereal, Nuts & Snacks icon Cereal, Nuts & Snacks
Cheese icon Cheese
Coffee icon Coffee
Fresh Fruit & Vegetables icon Fresh Fruit & Vegetables
Individual Quick Frozen (IQF) icon Individual Quick Frozen (IQF)
Liquids icon Liquids
Meat, Poultry & Fish icon Meat, Poultry & Fish
Medical Devices & Supplies icon Medical Devices & Supplies
Medical Testing Kits icon Medical Testing Kits
Non-Food icon Non-Food Products
Pasta, Beans & Rice icon Pasta, Beans & Rice
Pet Food & Treats icon Pet Food & Treats
Pills & Capsules icon Pills & Capsules
Powders icon Powders
8SU-180

Options

  • NEW Standcap Pouch pouch configuration
  • Proprietary Viking robotic pick & place bag infeed system
  • Product filling – can be integrated with multi-head scales, volumetric fillers and auger fillers
  • Fully interlocked safety guards
  • Pre Sealing station for liquid or paste
  • Zipper opening device
  • Clean-in-place design
  • Long raised rotary shaft extender for longer bags
  • Extended bag magazine
  • Date coding: emboss, hot stamp, inkjet or thermal transfer
  • Quality control: checkweigher, metal detector, X-ray inspection
  • Dust suction nozzles and dust collector
  • Product settler
  • Bag supporter for heavy fills
  • Ethernet connectivity
  • Washdown structure (IP65 or IP66)
  • Steam or gas flush
  • Rotary running clockwise model
  • Bag rejection system
  • Collating discharge conveyor
